2023 Autel MaxiIM IM608 PRO Auto Key Programmer & Diagnostic Tool Plus APB112 Smart Key Simulator and G-BOX2

XP400 Pro adds support for following Chips:


EEPROM-->AMD-->AM29FXXX series chip

EEPROM--> FUJITSU-->MB29FXXX series chip

EEPROM-->ST-->M29FXXX series chip

Engine control module-->SIMTEC76(AM29F800BB) write

IMMO-->BENZ-->ESL_W209_W906 (Motorola) read/write/erase function

IMMO-->BMW-->EWS3 module read/write function

REMOTE_RENEW(renew key)-->NEC-->V51 and V5 chip read/write/erase



XP400 Pro adds support for the following adapter board:


APB113 PCF79XX adapter board

APB114 EWS3 adapter board

APB115 NEC Adapter board

APB118 NEC ELV adapter board

APB119 TB28FXXX adapter board

APB120 TMS370 adapter board

APB121 AM29FXXX adapter board

APB122 AM29FXXX adapter board 1

APB123 AM29FXXX adapter board 2

APB126 M35080/D80 adapter board

APB127 MC68HC0(7)05BXX adapter board

APB128 MC68HC05X32 adapter board


Advanced Key Programming Functions:


Exclusive Smart Mode to guide Key Programming

Auto Read IMMO Data via OBD

One-tap Key Programming via OBD & Easy-to-use Remote Programming

With the newly upgraded key programmer XP400 Pro

Extensive Vehicle & Functionality Coverage

Support Diagnostics & IMMO Programming for 10,000+ Models;

Support Models Up to 2020;

All System Diagnostics and Advanced Maintenance Services;

Benz -- 3rd Generation IMMO CAN-Line / K-Line Add Key, All Key Lost via OBD;

BMW -- Support EWS3/4; CAS 1/2/3/4, FEM/BDC Add Key / All Key Lost;

Volkswagen / Audi -- Add Key / All Key Lost via OBD for 2013 - 2020 Models;

GM -- Read IMMO Password, Add Key / All Key Lost up to 2020;

Ford -- Add Key / All Key Lost (No PIN Needed) up to 2020;

Mazda -- Add Key / All Key Lost (No PIN Needed) up to 2020;

FCA -- Read IMMO Password, Add Key / All Key Lost up to 2020;

Renault -- Add Key / All Key Lost (No PIN Needed) up to 2020

Jaguar LandRover -- Add Key / All Key Lost up to 2019

Volvo -- Semi-smart Key Learning via OBD up to 2018; Smart / Blade / Fobik Key Learning via Dump



Package Includes:


1pc x MaxiIM IM608 Tablet

1pc x XP400 Pro Key Programmer

1pc x MaxiFlash JVCI ECU Reprogrammer

1pc x Carry Case

1pc x Main Cable

1pc x USB Cable (2m)
1pc x Connect Cable

1pc x Mini USB Cable

1pc x AC/DC Adapter (12V)

1pc x Light Fuse - 6*30mm (2pcs)

1pc x Cigarette Lighter

1pc x AAC001

1pc x APC101 (USB Cable)

1pc x APB129 (EEPROM Adapter)

1pc x APB125 (Mercedes Infrared Collector)

1pc x APB104 (MCU_FQFP64)

1pc x APB105 (MCU_FQFP80)

1pc x APB106 (MCU_FQFP112)

1pc x APB107 (MCU_FQFP144)

1pc x APB108 (MCU_FQFP176)

1pc x APA002 (EEPROM Socket)

1pc x APA101 (Signal Cable)

1pc x APA103 (EEPROM Clamp)

1pc x APA107 (ECU Clamp)

1pc x APA108 (MCU Clamp)

1pc x APA109 (MC9S12 Clamp)

---

Original AUTEL APB112 Smart Key Simulator Works for Autel MaxiIM IM608/ IM508

US Warehouse -Fast Ship & NO TAX

Autel APB112 Features:

• Smart key simulator
• Compatible with IM608, IM508, IM608 Pro
• Compatible with XP400 for 4D transponder functions
• 46, 4D data collection
• Smart key password calculation (Hyundai/Kia 46)
• 46 chip simulation
• Toyota 4D (94/D4, 98) smart key simulation
• Toyota H (88/A8, A9, 39) smart key simulation
• Collects data from the ignition coil
• Identifies ignition coil troubles
• Decodes vehicle key chip data
• Simulate vehicle key chip (ex - 4D chip)
• Used with Autel diagnostic tool
• Toyota/Lexus smart key all key lost
• Chip decoding (Hyundai 46)

• Notice:

  1. Do Not disconnect the USB Cable when use
  2. Can Not be working itself only. the APB112 Smart Key Simulator needs to be used together with the Autel Diagnostic Device.
  3. Compatible with IM608, IM508, and MX808IM (If you try to use the Autel G-box with IM508, you need to have the XP400. Otherwise the Autel G-Box can not work with IM508 )
  4. Before operating or maintaining this unit, please read these instrucstions carefully, pay extra attention to the safety warnings and precautions. Use this unit correctly and properly.
  Failure to do so may cause damage and/ or personal injury and will void the product warranty


How does Autel APB112 Work?


Please Note:

• The APB112 Smart Key Simulator needs to be used together with the Autel Diagnostic Device;
• Do Not disconnect the USB Cable when in use;
• If you try to use the Autel G-box with IM508, you need to have the XP400. Otherwise the Autel G-Box can not work with IM508;
• Before operating or maintaining on this unit, please read the instruction carefully, pay extra attention to safety warnings and precautions.

How to connect APB112 key simulator?

1. Connect the APB112 smart key simulator to Autel Diagnostic Device with the supplied USD cable;
2. Complete the connection, status indicator lights solid blue, indicating that the APB112 smart key simulator is working properly. Then it will communicate with the diagnostic device automatically.
3. According to the selected vehicle system function, the APB112 smart key simulator application is automatically upgraded on the Autel diagnostic device;
4. In order to decode the chip, please place the smart key simulator close to the ignition coil for data collection. After decoding, the original car chip data can be copied;
5. The emulator key chip can generate various types of key chips by performing subsequent upgrades as needed.

Demo: Program Toyota Camry 2016 All Smart Keys Lost with Autel IM508 & APB112


Package Includes:

1pc X APB112 Smart Key Simulator
1pc X USB Cable

---

Product Introduction:
The Autel G-BOX2 accesorry tool is an adapter which is compatible with Autel's IM508 + XP400 programmer and IM608 key programming tablets to aid in programming keys for Mercedes DAS3 CAN EIS/EXS in an AKL(ALL-Keys-Lost) situation.

The G-Box2 also supports DME/DDE ISN reading and writing in Boot mode on some BMW vehicles that are applicable. It can be used in Boot mode or Bench method.

Product Highlights:

Reads and writes Bosch engine ECU on F classis of BMW and MQB of Volkswagen.
Work with the Autel’s advanced diagnostic tablets supporting IMMO and key programming functions.
Program keys for Mercedez-Benz vehicles with DAS3 CAN EIS/EZS in AKL(ALL-Keys-Lost) situation.
Works with Autel IM508+XP400 and IM608, IM608 Pro, Auro IM600 and Auro IM100 with XP400. Note: The functions are NOT universal, please contact us to check before purchase.
Supports DME/DDE ISN Reading and Writing in Boot Mode on BMW vehicles that are applicable.
Reduce the data reading time of ECU W204 and EIS W207 by over 85%; It is not necessary to remove and reinsert the key for W221 and W164 after the 2009 models.
It can be used in Boot mode or Bench method.
Compare with other adapters, it is more effctive to read the ECU data from W204 and W207 EISs.



Product Functions:

Supports Mercedes Benz All Keys Lost, faster to calculate password
Supports IM608 or IM508 with XP400
Used for Faster Mercedes ECU data and EIS password calculation
Mercedes DAS3 can EIS/EZS all keys lost
Reduces reading time of W204 ECU data & W207 EIS by over 85%
No need to remove and reinsert the key for W221 & W164 after 2009 models
Read and write BMW DME/DDE ISN in boot mode
Compatible with Auro IM600 & Auro IM100 with XP400

Troubles and Troubleshooting:

When all the keys of the Mercedes-Benz vehicle are lost, you can operate via the OBD.
Note: This method is suitable for Mercedes-Benz W204, W207, W216 and W164 EISs after the year 2009.

Connection:

1. Connect the G-Box2 to the vehicle' s OBDII
2. Remove the fuse of vehicle EIS, connect the Relay ports to the fuse using the supplied fuse cable
3. When the vehicle has an ELV, connect the K7 port and ELV plug using the supplied K-line cable
4. Connect the G-Box2 to the Autel Diagnostic Tablet (MaxiIM IM608, IM508)

How to do in Bench method when all keys of Mercedes-Benz vehicle are lost?

Note: This Method is suitable for all Mercedes-Benz EISs that are already supported by Autel diagnostic tablets.

Connection:

1. Plug the G-Box2 to the Mercedes-Benz EIS using the packed DB15 Cable
2. Plug to the DC port of G-Box2 using a power adapter (DV 12V)
3. Plug the G-Box2 to the Autel diagnostic tablet (MaxiIM IM608, IM508)

Package Includes:

1pc x Autel G-BOX2
1pc x DB15 Cable
1pc x K-Line Cable
1pc x Fuse Cable
2pcs x Fuse (5A)
2pcs x Clamp Cable
1pc x OBDII Extension Cable
1pc x Quick Reference Guide
