[Auto Version] KT200 ECU Programmer Basic Auto Version with 7 License Supports Checksum Calculation with Paper Box

Product Description

2022 New KT200 ECU Programmer Master Version Support ECU Maintenance Chip Tuning DTC Code Removal OBD/BOOT/BDM/JTAG Multiple Protocols- Auto Version

Product Introduction:



 KT200 ECU programmer supports ECU maintenance chip tuning, DTC code removal, OBD/BOOT/BDM/JTAG, and multiple protocols. The hardware of  KT200 ECU programmer is Master version.


Master: Read and write ECU data, read it in BIN unencrypted format, you can modify the data arbitrarily, you can clone ECU and use it as ECU service, the master is a personal version, you can only use it yourself, cannot unlock data for the slave.

The master is a personal version of the device, which can be used freely after purchase. You can obtain our company's service software ECUHELP for free. All functions on the software are free to use. The software provides ECU model query, wiring diagram search, virtual data download, DEMO download, and free software library. And Data modifier number change expert software.

Feature:
Software version 22.08.20
Basic version KT200 with 7 license, Master version
Supports Car OBD, Truck OBD, Full System, BDM/JTAG, TOOL BOOT, Bench Mode, TCU Gear modules
Supports Checksum Calculation
Can be updated to full version
Full read and write TCU (Micro+EEPROM)
TCU Clone
TCU Coding
Covering up to 5400 ECU, over 500 TCU.
Auto Version Update to FULL Version is 250 USD
Get free VR files and Damaos files from ECUHelp 3.0 Software
Multi-language: Italian, English, Dutch, French, Spanish, Polish, Portuguese, Czech, Romanian, Turkish
Supports large amount of TCUs, i.e Volvo MPS6, VAG DQ400e/SQ100, Jeep 9H28 TCUs
Free update no annual fee (If you want to add new modules in future, need pay for new modules)
More Details on the official website https://www.ktm200pro.com

Operating system:
Windows 7
Windows 8/8.1
Windows 10
Windows 11

Minimum Recommended Requirements:

CPU > 2.5 GHz (Intel i5, i7)
RAM > 8GB

NOTE:
1. Must connect software online to access our server, no lock issue.
2. DCM7.1 will be available in the next updates.
3. It can do a full backup of edc15 (flash+eeprom) by pinout. No need to open and boot mode which is a rare feature.

Free Download
KT200 22.08.20 Software
KTM200 ECU list
KT200 TCU list
KT200 wiring diagram

Product Function:

Japanese, American and Chinese models

EGR & DPF Removal, IMMO OFF, releasing speed limit , mileage correction, Hot start or Cold Start Vmax, and so on.

The list of vehicles is constantly updated, which keeps you at the forefront of the industry.

Support Volkswagen Audi clone(local operation without sending data to manufacturers)

ECU maintenance, Chip tuning, DTC code Removal, professional reading and writing equipment covering 99% of the models in the market.

Read and write ECU data, and the data can be used for ECU services.

What is the ECU service?

ECU service includes 2 major items:


1. Chip tuning.

Chip tuning is to improve engine performance by modifying the data read out by the equipment. The data is divided into: Stage 1 data,  Stage 2 data, and  Stage 3 data.



2. ECU maintenance.

ECU maintenance data is to repair software errors in the ECU and some identity data of the ECU by modifying the data read by the device. We provide the following items:DTC code Removal





Software: The software of KT200 Auto version includes 7 licenses:


Car OBD, Truck OBD, Full System, BDM/JTAG, TOOL BOOT, Bench Mode, TCU Gear



Professional software for reading and programming the control units of car and truck



Additional TCU package available for Automatic Transmissions.



Full Read And Write Via Pin Out in Bench Mode:

BOSCH EDC7

BOSCH EDC16

BOSCH ME9/MED9



Full Read And Write Via Pinout in Bench Mode:

BOSCH MD1

BOSCH MG1

-FREESCALESPC5777

-AURIXTC29x

-STSPC58



Full Read And Write Via Pinout in Bench Mode:

BOSCH EDC17

BOSCH MED17/ME17

SIEMEN SPCR2.1

(Unlocking also possible via pinout)





Full System Via Pin Out (Micro/Flash+EEPROM)of ECUs:

BOSCH

CONTINENTAL

DELCO

DENSO

MARELLI

SIEMENS

TEMIC

TEMIC



BDM EJTAG Modes For:

BDM MPC55x

BDM MPC56x

BDM MC32/ZC32

BDM HC12/S12x

JTAG NEXUS MPC/SPC56xx

JTAG NEXUS MPC55xx



JTAG RENESAS

SH7055

SH7058

SH7059

SH7251

SH72543

SH72544

JTAG NEC76F00xx

76F0038AGD

76F0038GD

76F0039AGD

76F0039GD

76F0040GD

76F0070

76F0070

76F0085



BOOT Modes:

-BOOT MODEC16729Fxxx

-BOOT MODE ST K-LINE/RX-TX/CAN

ST10F168

ST10F269

ST10F273

ST10F275

ST10F276

ST10F276

ST10F280

ST10F296

 -BOOT Mode Tricore for micro

TC1724

TC1728

TC1738

TC1738

TC1762

TC1766

TC1767

TC1782

TC1791

TC1792

TC1793

TC1793

TC1796

TC1797

-BOOT Mode Renesas

SH7052

SH7054

SH7055

SH7055

SH7058

SH7059

SH7251

SH72543

SH72544

-BOOT Mode Mitsubishi

MH7202

MH7203

MH8102F

MH8105F

MH8106F

MH8202

MH8206F

MH8301F

MH8301F

MH8304F

MH8405F

-BOOT BAM System MOTOROLA

SPC5674

SPC5777

-BOOT MODE Fujitsu

-BOOT MODE Hitachi



Additional Package For Automatic Transmission


Full Read And Write TCU(MICRO+EEPROM)

TCU CLONING

TCU CODING FUNCTIONS



Compatible Operating Systems:



Windows 7

Windows 8/8.1

Windows 10

Windows 11!



Minimum Recommended Requirements:



CPU > 2.5 GHz (Intel i5, i7)

RAM > 8GB
